RAPIX DALI Two Channel Relay, 10Amp / Channel Inductive relay

General purpose load switching (ON and OFF) via received DALI commands.
Capable of switching 12 AX @ 240 V ac.
Suitable for mains voltages 100 V – 240 V ac, 50/60 Hz.
500 Amp (2 ms) inrush current rating.
Zero crossing detection to maximise relay contact life on relay close operation.
LED indicators (DALI, power, and for each load channel).
Each channel uses a single DALI Short Address; can be including in up to 16 DALI Group Addresses and/or up to 16 DALI Scenes.
DALI Short Address, Group Addresses and DALI Scenes are configured using RAPIX Addressing or RAPIX Integrator software. Can also be commissioned using other DALI commissioning software that supports DALI Device Type 7.
Complies with DALI-2 standard IEC 62386 and Device Type 7 (Switching Function).

£137.81 + VAT

SKU DGOZ-RLY-10A-02 Category Rapix Tag Ozuno Rapix DALI2

Description
Brand

Description

The RAPIX DALI two channel relay are designed for on/off switching of up to 10 Amps of lighting load using received commands DALI commands.

The on-board 240 V ac rated relay is capable of switching a full 10 A of LED, fluorescent, incandescent and HID lighting loads, suitable for a wide range of commercial and industrial building applications.
